| WEIGHT |
12.30 kg |
| ISO norm |
ISO 4210-2 Young Adult\t |
| EN norm |
EN17406 Condition 2 For on and Off-Road riding and drops less than 15cm |
| LOAD CAPACITY |
75 kg |
| FRAME |
Alu X6 Ultralite, Race Geometry, Integrated Cable Routing, BB92, SR
dropout, Boost Thru axle 148x12mm, Inner cable routing. |
| SUSPENSION FORK |
RockShox Judy Silver TK R, Tapered, SoloAir, 15x110mm axle, 100mm travel |
| BOTTOM BRACKET |
SHIMANO BB-MT500PA, PressFit, shell 41x92mm |
| HEADSET |
ACROS AZX-212 R5, ZS44/28.6 - ZS56/40 |
| REAR AXLE |
SB01, TA12x171.5, M12xP1.5x15.5L, Black |
| SHIFTERS RIGHT |
SHIMANO DEORE SL-M6100-IR, RAPIDFIRE Plus, 12-speed |
| REAR DERAILLEUR |
SHIMANO SLX RD-M7100, Shadow Plus Design |
| CRANKSET |
ONE Race, Alloy, 165mm, 32T |
| CASSETTE |
SHIMANO DEORE CS-M6100, 12-speed, 10-51T |
| CHAIN |
SHIMANO DEORE CN-M6100 |
| BRAKE FRONT |
SHIMANO MT410, hydraulic disc brake |
| ROTOR FRONT |
SHIMANO SM-RT30, 160mm |
| BRAKE REAR |
SHIMANO MT410, hydraulic disc brake |
| ROTOR REAR |
SHIMANO SM-RT30, 160mm |
| HUB FRONT |
SHIMANO HB-MT410-B, 28H, CL, 15x110mm, THRU Type AXLE |
| RIM FRONT |
STARS J20S, Disc, 28H |
| TIRE FRONT |
Schwalbe Racing Ray Performance, TwinSkin, TL-Ready, 27.5x2.25",
ADDIX |
| HUB REAR |
SHIMANO FH-MT410-B, 28H, CL, 12x148mm, THRU Type AXLE |
| RIM REAR |
STARS J20S, Disc, 28H |
| TIRE REAR |
Schwalbe Racing Ralph Performance, TwinSkin, TL-Ready, 27.5x2.25",
ADDIX |
| SPOKES |
SAPIM Laser/Race, Stainless Black |
| NIPPLES |
SAPIM, Brass |
| HANDLEBAR |
ONE Alloy Integrated Cockpit |
| GRIPS LEFT |
ONE Sport, Lock-On |
| GRIPS RIGHT |
ONE Sport, Lock-On |
| SADDLE |
Selle Royal Mini Vivo |
| SEATPOST |
ONE Race, Carbon, 27.2mm |
| SEATPOST CLAMP |
ONE CC-617, 31.8mm, with Quick Release level, Black |
