| WEIGHT |
11.50 kg |
| ISO norm |
ISO 4210-2 MTB bicycles |
| EN norm |
EN17406 Condition 3 For rough Off-Road riding and jumps less than
60cm |
| LOAD CAPACITY |
120 Kg |
| FRAME |
SU-01.2, Carbon MTB Race Pro, Advanced Race Geometry, Travel 110-120 mm,
Integrated Cable routing, BB92, 3D alloy one pice link, Carbon swingarm, SR
dropout, Boost Thru Axle 148x12 mm, Inner cable routing, Dropped seat post
ready |
| SUSPENSION FORK |
DT Swiss F232 ONE, Tapered, 15x110mm axle, 120mm travel |
| REAR SHOCK |
DT Swiss R232 ONE, size 190x45mm, ODL |
| BOTTOM BRACKET |
SHIMANO BB-71-41A, PressFit, shell 41x92mm |
| HEADSET |
ACROS AZX-1305R1S, ICR, ZS56/28.6 - ZS56/40, BlockLock 150°, Stainless
Bearings |
| REAR AXLE |
SB02-LT, TA12x175.5, M12x1,0x14.5L, Light, Black |
| SHIFTERS RIGHT |
SHIMANO XT SW-M8250-IR, Di2, 12-speed |
| REAR DERAILLEUR |
SHIMANO XT RD-M8250, Shadow Plus Design |
| CRANKSET |
SHIMANO XT FC-M8200, 34T |
| CASSETTE |
SHIMANO XT CS-M8200, 12-speed, 10-51T |
| CHAIN |
SHIMANO XT CN-M8100 |
| BRAKE FRONT |
SHIMANO XT M8200, hydraulic disc brake |
| ROTOR FRONT |
SHIMANO RT-CL800, 180mm |
| BRAKE REAR |
SHIMANO XT M8200, hydraulic disc brake |
| ROTOR REAR |
SHIMANO RT-CL800, 160mm |
| WHEELSET FRONT |
DT Swiss XRC 1700 SPLINE®, Carbon, CL, 15x110mm, Tubeless Ready |
| WHEELSET REAR |
DT Swiss XRC 1700 SPLINE®, Carbon, CL, 12x148mm, SH12, Tubeless Ready |
| TIRE FRONT |
Schwalbe Rick Evo, TL-Ready, XC Pro, 29x2.4", ADDIX Speed |
| TIRE REAR |
Schwalbe Rick Evo, TL-Ready, XC Pro, 29x2.4", ADDIX Speed |
| HANDLEBAR |
ONE Carbon Integrated Cockpit ICR |
| GRIPS LEFT |
ONE Race, Lock-On |
| GRIPS RIGHT |
ONE Race, Lock-On |
| SADDLE |
Fizi:k Ridon X5, Alloy |
| SEATPOST LEVER |
SHIMANO SL-MT500-L, Seat post lever |
| SEATPOST |
ONE Sport Dropper Post, Alloy, 30.9mm |
| SEATPOST CLAMP |
ONE CC-080A, 34.9mm, Black |
